浏览器网页如何直接访问客户端电脑文件

2025-05-28 04:39:59

1、创建C#类库项目：ImageActiveX使用VS开发工具新建 C# .net framework 类库->选择.net framework 4.6->项目取名“ImageActiveX”；

2、ImageActiveX项目右击应用程序->属性->应用程序->程序集信息->然后选中“使程序集COM可见”

3、ImageActiveX项目右击应用程序->属性->生成->然后选中“为COM互操作注册”

4、ImageActiveX项目新建类Main.clas衡痕贤伎s 代码如下：using System;using System.Collectio荏鱿胫协ns.Generic;using System.Drawing;using System.Drawing.Imaging;using System.IO;using System.Linq;using System.Runtime.InteropServices;using System.Text;using System.Threading.Tasks;namespace ImageActiveX{ [ComImport, GuidAttribute("CB5BDC81-93C1-11CF-8F20-00805F2CD064")] [InterfaceTypeAttribute(ComInterfaceType.InterfaceIsIUnknown)] public interface IObjectSafety { [PreserveSig] int GetInterfaceSafetyOptions(ref Guid riid, [MarshalAs(UnmanagedType.U4)] ref int pdwSupportedOptions, [MarshalAs(UnmanagedType.U4)] ref int pdwEnabledOptions); [PreserveSig()] int SetInterfaceSafetyOptions(ref Guid riid, [MarshalAs(UnmanagedType.U4)] int dwOptionSetMask, [MarshalAs(UnmanagedType.U4)] int dwEnabledOptions); } [Guid("E52C3E70-B486-4743-B8AE-5D830A561442")] public partial class Main : IObjectSafety { private const string _IID_IDispatch = "{00020400-0000-0000-C000-000000000046}"; private const string _IID_IDispatchEx = "{a6ef9860-c720-11d0-9337-00a0c90dcaa9}"; private const string _IID_IPersistStorage = "{0000010A-0000-0000-C000-000000000046}"; private const string _IID_IPersistStream = "{00000109-0000-0000-C000-000000000046}"; private const string _IID_IPersistPropertyBag = "{37D84F60-42CB-11CE-8135-00AA004BB851}"; private const int INTERFACESAFE_FOR_UNTRUSTED_CALLER = 0x00000001; private const int INTERFACESAFE_FOR_UNTRUSTED_DATA = 0x00000002; private const int S_OK = 0; private const int E_FAIL = unchecked((int)0x80004005); private const int E_NOINTERFACE = unchecked((int)0x80004002); private bool _fSafeForScripting = true; private bool _fSafeForInitializing = true; public int GetInterfaceSafetyOptions(ref Guid riid, ref int pdwSupportedOptions, ref int pdwEnabledOptions) { int Rslt = E_FAIL; string strGUID = riid.ToString("B"); pdwSupportedOptions = INTERFACESAFE_FOR_UNTRUSTED_CALLER | INTERFACESAFE_FOR_UNTRUSTED_DATA; switch (strGUID) { case _IID_IDispatch: case _IID_IDispatchEx: Rslt = S_OK; pdwEnabledOptions = 0; if (_fSafeForScripting == true) pdwEnabledOptions = INTERFACESAFE_FOR_UNTRUSTED_CALLER; break; case _IID_IPersistStorage: case _IID_IPersistStream: case _IID_IPersistPropertyBag: Rslt = S_OK; pdwEnabledOptions = 0; if (_fSafeForInitializing == true) pdwEnabledOptions = INTERFACESAFE_FOR_UNTRUSTED_DATA; break; default: Rslt = E_NOINTERFACE; break; } return Rslt; } public int SetInterfaceSafetyOptions(ref Guid riid, int dwOptionSetMask, int dwEnabledOptions) { int Rslt = E_FAIL; string strGUID = riid.ToString("B"); switch (strGUID) { case _IID_IDispatch: case _IID_IDispatchEx: if (((dwEnabledOptions & dwOptionSetMask) == INTERFACESAFE_FOR_UNTRUSTED_CALLER) && (_fSafeForScripting == true)) Rslt = S_OK; break; case _IID_IPersistStorage: case _IID_IPersistStream: case _IID_IPersistPropertyBag: if (((dwEnabledOptions & dwOptionSetMask) == INTERFACESAFE_FOR_UNTRUSTED_DATA) && (_fSafeForInitializing == true)) Rslt = S_OK; break; default: Rslt = E_NOINTERFACE; break; } return Rslt; } } public partial class Main { public string SayHello() { return "Hi I'm from ActiveX Compliled by C#!"; } public string SetData(string input) { return input; } public string Image_GetBase64(string imagePath) { if (string.IsNullOrWhiteSpace(imagePath)) { return "出错了：你传入参数为空！"; } if (!File.Exists(imagePath)) { return "出错了：你传入的图片文件不存在！"; } try { Bitmap tmpBitmap = new Bitmap(imagePath); string tmpBase64 = ""; using (MemoryStream ms = new MemoryStream()) { tmpBitmap.Save(ms, ImageFormat.Jpeg); byte[] tmpByteData = new byte[ms.Length]; ms.Position = 0; ms.Read(tmpByteData, 0, (int)ms.Length); ms.Close(); tmpBase64 = Convert.ToBase64String(tmpByteData); } return tmpBase64; } catch (Exception ex) { return string.Format("出错了，读取图片转base64异常：{0}", ex.Message); } } /// <summary> /// 将Base64的图片保存到指定位置 /// <returns></returns> public bool Image_SaveToLocal(string imgBase64,string img_SavePath) { //自己添加自己的方法 return true; } }}

5、创建插件安装程序：ImageActiveXSetUpVS新建项目选择：“SetUp Project” 或者 “安装项目”；本项目不需要写任何代码只是做安装配置即可；可选择项目按F4 进行具体的安装配置设置；

6、如果没有“SetUp Project” 或者 “安装项目”这个两个选项，需要手动安装扩展插件：VS菜单->扩展->管理扩展->搜索安装：Microsoft Visual Studio Installer Projects

7、ImageActiveXSetUp项目右键->添加(Add)->项目输出->项目：选择ImageActiveX插件项目

8、编译程序打包项目（ImageActiveXSetUp）：生成Setup.exe文件和ImageActiveXSetUp.msi安装文件；

9、在本地双击运行Setup.exe文件安装插件：


11、最终测试效果如下图：
